RS485 Modbus-RTU Smart Motor Protector /380v Motor Controller ARD2F

Name: RS485 ModbusRTU Smart Motor Protector 380v Motor Controller ARD2F
Brand: Acrel
Price: 265.00 USD

Quality RS485 Modbus-RTU Smart Motor Protector /380v Motor Controller ARD2F for sale

Place of Origin : Jiangsu, China

Brand Name : Acrel

Model Number : ARD2F

Supply Ability : 8000 Piece/Pieces per Day

Packaging Details : It is packed in a crash bag and then put into a cardboard box.

MOQ : >=1 Pieces

Price : $265.00

Display Type : Analog and Digital

Phase : Three Phase

Measuring Energy Range : AC85V-265V/DC100V-350V

Accuracy Class : 1.5

Output Voltage : AC85V-265V/DC100V-350V

Operating Temperature : -10~55℃

Dimensions : 81.5mm*86mm*90mm

Communication : RS485 Port MODBUS-RTU Protocol

Display : LCD Display

Certificate : CE ISO9001

Installation : 35mm Din Rail

Function : Measurement

Power consumption : 15VA

Auxiliary power supply : AC85V-265V/DC100V-350V

Frequency : Range: 45-65Hz

Accuracy : 1.5

SOE event recorder : Record 8 fault messages

Port : SHANGHAI

Contact Now

RS485 Modbus-RTU Smart Motor Protector /380v Motor Controller ARD2F

ARD2F Smart Motor Protector

● Measurement functions are divided into basic measurement (current parameter) and co-selection measurement (voltage, power, phase
sequence, residual current (leakage current);
● Start timeout, overload, stall, block, underload, phase failure, unbalance, residual current (ground/leakage), temperature,
external fault, phase sequence, overvoltage, undervoltage, underpower, overpower, tE time Motor comprehensive protection function;
● 9-channels DI passive dry node input, signal power supply with built-in DC24V power supply;

● 5-channels DO output, which can meet the direct start, star-delta start, autotransformer start, soft start and other starting
modes. Real-time remote control "start/stop" operation of the remote master station can be realized through the communication bus;
● It has standard RS485 communication interface and adopts Modbus-RTU and Profibus-DP communication protocol to ensure fast and
reliable communication of the host computer;
● It has a DC4-20mA analog output interface and is directly connected to the DCS system to monitor the field devices.

Characteristic

Communication

RS485 (Modbus-RTU)

Display

LCD display for U, I, P, Q etc

Rated U and I

AC380/660V, rated current up to 800A

Function

Accuracy

U, I: Class 1.5

Frequency
Range: 45-65Hz

Auxiliary power supply
AC85V-265V/DC100V-350V

SOE event recorder
Record 8 fault messages

Installation:
1. Main body: DIN 35mm
2. Display unit: Panel mounted

Dimension(L*W*H):
81.5mm*86mm*90mm

Technical Parameters

Parameters	Technical specification
Auxiliary power supply	AC85~265V/DC100~350V, power consumption 15VA
Rated voltage	AC380V/AC660V,50Hz/60Hz
Relay output contactor Rated negative capacity	5 channels, AC250V 6A
Switching input	9 channels,opto-coupler insolation
Communication	RS485(Modbus RTU)
Environment	Operation temperature	-10℃~55℃
		Storage temperature	-20℃~65℃
		Relative humidity	5%~95%(No condensation)
		Altitude	≤2000m
Class of pollution	Level 2
Protection level	Main module IP20,display unit IP45
Installation category	Class III

Appearance

Wiring

Product Application

Customer Photos

Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd.

baojingjun@email.acrel.cn
Address:No.5,Dongmeng Road,Nanzha Town,Jiangyin City,Jiangsu Province.

FAQ

1. Q: Where is your factory located ? How can I visit here ? Can your factory arrange transportation for me?

A: Our production base is located in Jiangyin City, Jiangsu Province, China; Which will take about 2 hours by car from Shanghai to our factory. We can arrange our driver to pick you up from your hotel when you arrive Shanghai.

2. Q: Does your factory have the design and development capabilities, can you factory accept customized products?

A: The staffs in our R&D department are well experienced in the Electric industry, with more than 10 years’ experience. We can make customized products especially for you; please kindly contact us for more

3. Q: How long could I get my order?

A: Stock Products: shipping within 5 days.

B: Customized products: usually 10-15 days. It depends on your design and quantity.

4. Q: How is your production management and quality control system?

A: All our product process follows up ISO9001. The strict implementation of ISO9001 assures to provide error–free products to our customers. We will show you these in our workshop during your visiting.

5. Q: How can I get a sample to check the quality?

A: We are glad to offer you samples for test. Leave us message of the item you want and your city address. We will offer you detail sample packing information, and select the best way to deliver it.
