Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter

Product Categories
Jiangsu Acrel Electrical Manufacturing Co., LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter

Place of Origin : Jiangsu, China

Brand Name : Acrel

Model Number : DDSD1352-CT

Supply Ability : 100000 Piece/Pieces per Month

Packaging Details : It is packed in a crash bag and then put into a cardboard box.

MOQ : >=1 Pieces

Certification : CE

Display Type : Digital Only

Phase : Single Phase

Accuracy Class : 1.0

Output Voltage : 220V

Operating Temperature : -25℃~55℃

Dimensions : 88mm×36mm×70mm

Maximum current : 60A / 100A

Reference voltage : 220V

Frequency : 50Hz

Communication : RS485 Modbus-RTU

Contact Now

Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter
Product Description
Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter
DDSD1352-CT is with high class, small volume, easy installation etc. advantage, it could be used in electric distribution box to realize the measurement, statistics and analysis of the different electric energy in different district and electric load. It is fitted with RS485 communication port and adapted to MODBUS-RTU. ADL can be used in all kinds of control systems, SCADA systems and energy management systems.

Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter

Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter energy meter is designed for power supply system, industrial and mining enterprises and utilities to calculate the electricity consumption and manage the electric demand. It features the high precision, small size and simple installation. It integrates the measurement of all electrical parameters with the comprehensive electricity metering and management provides various data on previous 12 months, checks the 31st harmonic content and the total harmonic content, realizes the remote communication and the remote control with switching input and relay output and boasts the alarm output.
Function & Parameter
Model
ADL100-ET
Phase
Single phase
Rated voltage
AC220V
Consumption
≤10VA
Reference frequency
50HZ
Maximum current
60A
Starting current
0.0041b
Consumption
≤4VA
L*W*H(mm)
36*88*70 mm
Mounting
Din rail 35mm
Communication
RS485-MOBUS(C)
Working temperature
-20℃~+60℃
Storage temperature
-30℃~+70℃
Humidity
≤95%(without condensation)
Altitude
<2000m

Details Images
Acrel DDSD1352-CT Single Phase Digital Energy Meter for Solis inverter
